Heavy-duty Horizontal Lathe

Specification parameters Max. swing diameter of bridge 2200mm Width of bridge 500mm Max. swing diameter of slide carriage 1300mm Max. swing diameter of bed way 1800mm Max. workpiece length 3m-16m Center height 1150mm Max. stroke of lathe bed 3200mm Stroke of large slide carriage 900mm Stroke of slide carriage 800mm Chunk diameter (customized option) 2000mm Lathe loading capacity 15T Diameter of spindle center hole 80mm Types of clockwise spindle speed 8 Clockwise spindle speed 3.52.4r.min¹ Standard of main motor 30KW Tailstock center driving motor 1.5KW Variable frequency motor of bed feed 3KW Traction motor of tailstock and bed 3KW
